Enterprise 220

Lay-in metal panel in exposed T bar grid

Enterprise 220 offers a durable and modularised exposed grid solution which can suit any building module. The metal ceiling panels are designed to lay-in an aluminium 2-way T Bar grid system. The solution provides installation ease, created by the snap-in grid which ensures panels and grid are installed in modularised straight lines. All panels are supported on all four sides, with the panels simply lifting out for maintenance and access.

This system is ideal for commercial offices, retail, healthcare and education.

Product Specification

Exposed Grid

Up to 1.0 NRC

Group 1

Recyclable

25 year warranty

Grid

24mm x 38mm aluminium T bar grid, exposed 2-way

Size
1500mm x 500mm, 500mm x 500mm, 1350mm x 450mm, 450mm x 450mm, 1200mm x 600mm, 600mm x 600mm.
Bespoke modules on request
Material

Steel
Aluminium

Pattern

Plain
Perforated
Mesh

Finishes

Polyester powder-coated (PPC)
Timber effect
Bespoke finishes on request

Acoustics

Acoustic fleece or acoustic pad.
Performance is dependent on pattern open area and infill.
Absorption: up to 1.0 NRC
Attenuation: up to 37dB

Environment

Global GreenTag GreenRate Level A
Low VOC
ISO 14001 and ISO 9001
Recyclable and designed for disassembly
Product stewardship program

Technical

Fire Test: NCC Group 1
Seismic: project specific
Services: integration supported
Warranty: 25 years
